Optica SE (Standard Edition)

光学モデル作成用Mathematica パッケージ

Optica はWolfram Mathematica に光学分野のオーサリング環境を提供する拡張機能ツールです。 Mathematica と同じくWolfram 言語を用いており、あらゆるバージョンのMathematica に対応しています。これにより作成されたインタラクティブな光学モデルは、エキスパートでしか操作ないしは理解不能な従来型モデルとは異なり、専門知識を持たない相手に対しても説得力を持つとともに、スタンドアロンでの動作が可能なためiPad やiPhone 上でのプレゼンテーションにも適しています。ベーシックパッケージのOptica SE は自由形式の光学設計が可能な他、使い始めの新規ユーザーでも短時間で光学モデルを作成できるよう工夫された編集ツールなど、数多くの新機能が含まれています。 また従来のバージョンに比べて、SolidWorks、Zemax、BeamWise といった他社の光学設計およびモデリングソフトウェアのユーザーとの共同作業のための機能も改善されています。

本バージョンの機能

  1. Sequential and non-sequential ray tracing in three-dimensional space
  2. Seamless integration with Mathematica
  3. Viewable source code
  4. GUI pulldown menus for defining systems and components.
  5. Java-based real-time controls
  6. Create standalone realtime models using the dynamic interactivity of Mathematica
  7. Input of CAD ( STL) models into system functions
  8. Number of component functions to use for defining optical components
  9. Number of predefined types of lenses: LensDoublet,SchmidtLens,CompoundLens, BallLens, PlanoConvexLens, etc ...
  10. Number of mirror functions: Mirror,BallMirror,AsphericMirror,SphericalMirror,CustomMirror, ParabolicMirror, etc...
  11. Number of prism functions: Solitaire,DovePrism,PolarizingPrism, AnamorphicPrisms, etc ...
  12. Number of light source functions : GaussianBeam, PointOfRays, GridOfRays, etc ...
  13. Aperture stops, pin-holes, and baffles
  14. Gratings
  15. Eye Model
  16. Fresnel-flattened lenses and mirrors
  17. Gain and absorption through bulk material
  18. Amplitude and optical path length (phase) information
  19. Arbitrary user-defined, optical surface profiles of any shape
  20. Randomized light sources and Monte Carlo ray-tracing
  21. Ray-trace speed-enhancements
  22. Graded-index refraction: lenses and optical fibers
  23. Diffuse surface scattering (including Lambertian)
  24. Linear polarisers, birefringent optics, retardation plates
  25. Jones matrix calculations
  26. Linear polarisers, birefringent optics, retardation plates
  27. Curved optical fibers
  28. Import files from Zemax ( refractive elements) and Code-V
  29. Polarization/wavelength-dependent optical coatings
  30. Searchable database of commercial optics and optical materials
  31. User-defined optical surface properties
  32. Analytic parametric descriptions of optical surface shapes
  33. Symbolic parameterization of optical system characteristics
  34. Optimization of arbitrary system parameters
  35. Polarization ray-tracing and birefringence
  36. Numeric ray-tracing of Gaussian beams
  37. Energy calculations: including models of gain and absorption
  38. Intensity plots at any surface
  39. Geometric Point Spread Function
  40. Diffractive Point Spread Function
  41. Modulation Transfer Function
  42. Coherent Transfer Function
  43. Pupil Function
  44. Seidel aberrations
  45. In-depth characterization of imaging optics
  46. Zernike-polynomial fit of wave front
  47. Interference calculations
  48. Wavefront calculations
  49. Holographic diffraction gratings
  50. Paraxial and higher-order symbolic calculations
  51. Arbitrary precision calculations of optical systems
  52. Symbolic optical path length
  53. Symbolic surface intercepts
  54. Symbolic intensity
  55. Gaussian-beam wavefront propagation
  56. Symbolic ABCD matrix analysis
  57. Symbolic global optimization of system parameters
製 品 名 税込標準価格
Optica SE DL 版 [年間サポートサービス・バンドル]
415,800 円
Optica SE 教育機関割引 DL 版 [年間サポートサービス・バンドル]
207,900 円
Optica 4 からのアップグレード DL 版 [年間サポートサービス・バンドル]
148,500 円

※ DL:ダウンロード
【ご使用上の注意】
  Wolfram Mathematica 上で使用する専用パッケージです。単独では動作しません。
